The Raspberry Pi 3 Model A+ is the latest product in the Raspberry Pi 3 range. Like the Raspberry Pi 3 Model B+, it boasts a 64-bit quad core processor running at 1.4 GHz, dual-band 2.4 GHz and 5 GHz wireless LAN, and Bluetooth 4.2/BLE.
The dual-band wireless LAN comes with modular compliance certification, allowing the board to be designed into end products with significantly reduced wireless LAN compliance testing, improving both cost and time to market.
The Raspberry Pi 3 Model A+ has the same mechanical footprint as the Raspberry Pi 1 Model A+.
|Processor:||Broadcom BCM2837B0, Cortex-A53 64-bit SoC @ 1.4 GHz|
|Memory:||512MB LPDDR2 SDRAM|
|Connectivity:||2.4 GHz and 5 GHz IEE 802.11.b/g/n/ac wireless LAN, Bluetooth 4.2/BLE|
|Access:||Extended 40-pin GPIO header|
|Video & sound:||
|SD card support:||Micro SD format for loading operating system and data storage|
|Input power:||5 V/2.5 A DC via micro USB connector 5 V DC via GPIO header|
|Environment:||Operating temperature, 0–50°C|
|Compliance:||For a full list of local and regional product approvals, please visit:
|Production lifetime:||The Raspberry Pi 3 Model A+ will remain in production until at least January 2023|
Raspberry Pi A+ Physical Specifications:
Note: Limit of 1 per customer during the launch.
Raspberry Pi 3 Model A+
We can get 10000 units in Australia from Raspberry Pi. If you order today, we can dispatch this stock between Mar 01, 2020 - Mar 03, 2020.
